Delivering it all in one solid bike featuring a a Bafang 1000w High Torque Mid Drive motor, 11 gears, topped with a 48v 21AH battery – no terrain is going to stop you! Paired with 26×4.5” fat tires and 4 Piston Hydraulic brakes, you have the recipe of a perfect hunting bike. From the mountains to the flat prairie, The Rebel Step Thru is ready to deliver you to your stand!

OUR BATTERY

Rambo’s frame integrated batteries allow the battery sit lower on the bike frame than a standard battery. Our integrated battery packs use the very best lithium ion batteries. Our integrated batteries are designed to be universal and allow you to upgrade to a whopping 21-amp hour battery! The 21-amp hour battery can give you a max distance of 48 miles! Not all batteries are equal. In fact, not even close. Many e-bikes that are advertised on the market today at a certain amp hour fall very short. Real life tests show Rambo outperforms again and again!

BAFANG 1000W HIGH TORQUE MID-DRIVE MOTOR

Rambo chose to use Bafangs BBSHD powerful mid-drive motor. The BBSHD has a nominal power rating of 1000W and a peak power rating of 1500W. The BBSHD has a reduction ratio of 1: 21.9 and a maximum torque of 160 N.m, Giving the rider great explosive force when taking off. This motor is suitable for riding on terrain such as mountains, sand and for those adrenaline seeking riders who love power.

TECHNICAL SPECIFICATIONS

WEIGHT: 69 lbs.
FRAME: Aluminum Alloy 6061
PAINT: TruTimber Viper Western Camo
MOTOR: Bafang 1000W High Torque Mid-Drive
DIGITAL DISPLAY: Bafang DPC18 LCD Screen
BATTERY: 48V 21ah
FORK: GT860 AIR
Rear Cassette: SRAM NX PG-1130 11-42T
FRONT HUB: JT-M9CF 150mm Sealed
REAR HUB: JT-M9CF 150mm Sealed
FRONT BRAKE: Tektro HD-E725 4 Piston Hydraulic 203mm
REAR BRAKE:Tektro HD-E725 4 Piston Hydraulic 180mm
CHAIN RING: Rambo Custom Built 36t Narrow Wide
TIRE: 26” x 4.5”
RIM: Double Wall W/O holes 100mm wide
PEDAL: WellGo B807DU
SADDLE: Selle Royal A027HEO
HANDLEBAR: ProMax 770mm
STEM: ProMax MA-50
GRIP: Sram XX1 100mm/122mm Lock On
MAX SPEED: 28mph
RANGE: Up to 48 miles
STAND OVER HEIGHT: 31"
FRAME SIZE: 19″ Medium
WEIGHT CAPACITY: 300 Lbs.

The Rebel Step Thru
