This scope excels in diverse environments, from dense forests to open plains. With a 30mm main tube diameter, it provides increased adjustment range for precise targeting. The newly designed Ballistic Turret and advanced reticle options ensure optimal performance in any situation.

Scope of delivery

Z5+ Rifle Scope
Microfiber cloth

Features

Longe-range capabilities
Newly Designed Ballistic Turret
3.5 – 18x magnification range
Increased adjustment range
Multiple reticle options: PLEX, BRS, BRW, 4W
Precise targeting for diverse environments

Versatility
The scope adapts to any backcountry challenge, whether shooting in forests, over rough terrain, or at long distances.

Target Identification
Higher magnification settings and a 50mm objective lens allow for better target identification and judgement at long distances, even in low-light conditions.

Long Range Shooting
With 18x magnification, a newly designed Ballistic Turret, and increased internal adjustment range, this scope ensures precise shooting at long distances, essential for hunting in open terrains or mountains.

Main Tube Diameter
30mm, allowing for more physical space and increased adjustment range.

Newly Designed Ballistic Turret
Advanced design with 3-times more adjustment range, featuring 4 color-dot rings and a two-rowed MOA scale ring, plus a locking mechanism and zero-stop function.

Magnification	3.5-18
Effective objective lens diameter	34.3-50 mm
Exit pupil diameter	9.5-2.8 mm
Exit pupil distance	95 mm
Field of view	10.1-2.1 m/100m
Field of view degrees	5.8-1.2 °
Field of view apparent	21 °
Diopter adjustment	-3 to +2 dpt
Light transmission	91 %
Twilight factor acc. to ISO 14132-1	9.9-30.0
Parallax correction	50-∞ m
Impact point correction per click (in / mm)	0.25 / 7.27
Max. elevation / windage adjustment range (m/100m / in/100yds)	82.8/82.8 2.3/2.3
Length in mm.	366 mm
Weight	560 g
Central tube diameter	30 mm
Functional temperature	-20 to +55 °C
Storage temperature	-30 to +70 °C
Submersion tightness	13 ft / 4 m water depth (inert gas filling)

Z5+ 3.5-18x50 P L BT
