The FDN 25X features a reengineered optical system to guarantee the sharpest image resolution possible throughout the 5-25 magnification range. Target acquisition for accurate shots beyond 2,000 yards is facilitated by the rapid adjustable 180° magnification throw. The ER3K elevation knob provides the shooter with the ability to perform eleven mils of correction per one revolution. The FDN 25X 5-25X features a 52mm objective, 6061-T6 aluminum 34mm tube, low-profile ER3K elevation knob with a zero stop, ergonomic capped US#1 windage knob, integrated illumination and parallax knob, rapid adjustable 180° magnification throw, and customization options that will undoubtedly meet your needs.

Objective Lens Diameter: 52 mm
Magnification: 5 - 25 x
Tube Diameter: 34 mm
Reticle Focal Plane: First Focal Plane (FFP)
Exit Pupil: 2 mm
Battery Type: CR2032
Field of View, Linear: 16.08 - 5.25 ft at 100 yds
Color: Matte Black
Weight: 33.38 oz
Fabric/Material: Aluminum
Length: 17.93 in
Width: 3.883 in
Height: 2.43 in
Illumination Type: LED
Illumination Color: Red
Parallax: 75 yds to infinity
Finish: Type III Hard Coat Anodized
Magnification Type: Variable
Elevation Travel: 23 MILS Total ; 19.3 MILS @ 20 MOA Down
Windage Travel: 10L/R (MILS)
